Tutorial Docker Arranging Kafka Delan UI Manager (Redpanda Console)

This time I will share a little tutorial on Docker Compose Kafka with UI Manager (Redpanda Console). Hope it helps friends who want to do Kafka setup easily and quickly for the development server.

Step Setup Kafka Broker + UI Manager (Redpanda Console) with Docker Compose

1. Create a folder to keep the file related to Kafka

mkdir kafka/
cd kafka/

2. The composition of the western file docker

vi docker-compose.yaml

services:
  zoo1:
    image: confluentinc/cp-zookeeper:7.3.2
    hostname: zoo1
    container_name: zoo1
    ports:
      - "2181:2181"
    environment:
      ZOOKEEPER_CLIENT_PORT: 2181
      ZOOKEEPER_SERVER_ID: 1
      ZOOKEEPER_SERVERS: zoo1:2888:3888

  kafka1:
    image: confluentinc/cp-kafka:7.3.2
    hostname: kafka1
    container_name: kafka1
    ports:
      - "9092:9092"
      - "29092:29092"
      - "9999:9999"
    environment:
      KAFKA_ADVERTISED_LISTENERS: INTERNAL://kafka1:19092,EXTERNAL://172.18.0.1:9092,DOCKER://host.docker.internal:29092
      KAFKA_LISTENER_SECURITY_PROTOCOL_MAP: INTERNAL:PLAINTEXT,EXTERNAL:PLAINTEXT,DOCKER:PLAINTEXT,EXTERNAL_PUBLIC:PLAINTEXT
      KAFKA_INTER_BROKER_LISTENER_NAME: INTERNAL
      KAFKA_ZOOKEEPER_CONNECT: "zoo1:2181"
      KAFKA_BROKER_ID: 1
      KAFKA_LOG4J_LOGGERS: "kafka.controller=INFO,kafka.producer.async.DefaultEventHandler=INFO,state.change.logger=INFO"
      KAFKA_OFFSETS_TOPIC_REPLICATION_FACTOR: 1
      KAFKA_TRANSACTION_STATE_LOG_REPLICATION_FACTOR: 1
      KAFKA_TRANSACTION_STATE_LOG_MIN_ISR: 1
      KAFKA_JMX_PORT: 9999
      KAFKA_JMX_HOSTNAME: ${DOCKER_HOST_IP:-127.0.0.1}
      KAFKA_AUTHORIZER_CLASS_NAME: kafka.security.authorizer.AclAuthorizer
      KAFKA_ALLOW_EVERYONE_IF_NO_ACL_FOUND: "true"
    depends_on:
      - zoo1

  console:
    image: docker.redpanda.com/redpandadata/console:v2.7.2
    entrypoint: /bin/sh
    command: -c "echo \"$$CONSOLE_CONFIG_FILE\" > /tmp/config.yml; /app/console"
    environment:
      CONFIG_FILEPATH: /tmp/config.yml
      CONSOLE_CONFIG_FILE: |
        kafka:
          brokers: ["172.18.0.1:9092"]
    ports:
      - "8080:8080"

Notes:

• Change the address in the following section: EXTERNAL://172.18.0.1:9092 And brokers: ["172.18.0.1:9092"]

Shop

3. Run Docker Compose

docker-compose up -d

Verification

Tips:

• Secure the web-UI port, Kafka-Broker, Zokeeper from the public. Allow only a particular IP address.
